Gasoline version
1.Engine type :Single Cylinder,4-Strokes |
2.start model: electric |
3.displacement:149.5ML |
4.ignition: CDI |
5.MAX speed: 60km/h |
6.Battery parameter: 12V/9AH Lead-acid |
7.brake: Four wheel disc brake |
8.front tyre: 4.00-10 |
9.rear tyre: 4.00-10 |
10.transmission:Chain + axis differential |
11.N.W: 198KG |
12.G.W: 245KG |
13.carton size: 2650*1150*650(mm) |
14.vehicle size:2650*1150*800(mm) |
15.Minimum turning diameter(m): 8 |
Electric version
1.Motor power :1500W |
2.Motor form: brushless motor |
3.Speed(KM): high speed 35KM low speed 15KM |
4.Extension mileage(KM): 40 |
5.top speed: 35km/h |
6.Battery parameter: 48V/20AH Lead-acid |
7.brake: disc brake |
8.front tyre: 4.00-10 |
9.rear tyre: 4.00-10 |
10.transmission: axis differential |
11.N.W: 180KG |
12.G.W: 225KG |
13.carton size: 2650*1150*650(mm) |
14.vehicle size:2650*1150*800(mm) |
15.Ground clearance:130(mm) |
16.Wheelbase( mm): 1450 |
17.Minimum turning diameter(m): 8 |
Gasoline version
1.Engine type :Single Cylinder,4-Strokes |
2.start model: electric |
3.displacement:149.5ML |
4.ignition: CDI |
5.MAX speed: 60km/h |
6.Battery parameter: 12V/9AH Lead-acid |
7.brake: Four wheel disc brake |
8.front tyre: 4.00-10 |
9.rear tyre: 4.00-10 |
10.transmission:Chain + axis differential |
11.N.W: 198KG |
12.G.W: 245KG |
13.carton size: 2650*1150*650(mm) |
14.vehicle size:2650*1150*800(mm) |
15.Minimum turning diameter(m): 8 |
Electric version
1.Motor power :1500W |
2.Motor form: brushless motor |
3.Speed(KM): high speed 35KM low speed 15KM |
4.Extension mileage(KM): 40 |
5.top speed: 35km/h |
6.Battery parameter: 48V/20AH Lead-acid |
7.brake: disc brake |
8.front tyre: 4.00-10 |
9.rear tyre: 4.00-10 |
10.transmission: axis differential |
11.N.W: 180KG |
12.G.W: 225KG |
13.carton size: 2650*1150*650(mm) |
14.vehicle size:2650*1150*800(mm) |
15.Ground clearance:130(mm) |
16.Wheelbase( mm): 1450 |
17.Minimum turning diameter(m): 8 |
